Usage of Tire Balers
Specially designed for compressing rubber products like car tires, truck tires, bus tires etc.
Features of Tire Balers
- Hydraulic-driven opening door ensures operational safety and easier opening& closing
- Two split platens with movable links to protect the platen from being distorted when pressing uneven materials like rubber tire etc
- Whole system manual control to make sure durability and simple operation
- Retractable retainer claws prevent the compacted bales to rebound
- Employ whole set Taiwan hydraulic system
- Mainly use Schneider electric components
- Employ Japanese A.M.C. oil pipe joint makes sure no oil leakage
- Auto chain bale ejector for easy operation and greater efficiency ( the bale can be automatically ejected out by the lifting chains)
- Front & Back opening doors for convenient strapping and bale ejecting
|
Model |
||
|
Pressure |
120tons |
120tons |
|
Power |
15kw |
22kw |
|
Baling Chamber Size (L*W*H) |
1530*790*1800mm |
2100*1200*2100mm |
|
Bale Size (L*W*H, H is adjustable) |
1530*790*(500-1200)mm |
2100*1200*(700-1400)mm |
|
Bale Size (L*W*H) After expansion |
1600*850*1200mm |
2200*1300*1400mm |
|
Bale Weight |
1tons |
1.9tons |
|
Machine Weight |
7tons |
12tons |
|
Machine Size (L*W*H) |
3734*1098*3700mm |
4231*1510*4300mm |
