baler machines

Soft Plastic Balers

Usage of Soft Plastic Balers

Widely used for compressing soft plastics like PE/PP Films

Features of Soft Plastic Balers

  • Automatic chain bale ejector for quickly and easily ejecting the bales out from the machine
  • Wide feed opening door lifts upwards automatically when the platen goes up
  • The ram will stop running downwards when the feeding gate is opened which ensure the safety of the operation
  • Equipped with independent emergency stop for safe operation
  • Equipped with Euro and U.S standard anti-rebound gate structure which makes sure the safety of operation
  • Special ram guides design makes the platen not slope because of uneven materials feedings during compression
  • Equipped with NOK seals that  from Japan means longer lifespan of the seals
  • Equipped with A.M.C. oil pipe joints that from Japan ensures the machine far away from oil leakage problems
  • Peculiar combination of motor and pump with direct-crossed connection makes sure 100 percent concentricity, which replacing the common coupling connection so that extend the lifespan of the pump

Model

XTY-300LE11070

XTY-500LE12080

Pressure

30tons

50tons

Feed Opening Size (L*H)

1100*500mm

1200*500mm

Baling Chamber Height

1400mm

1500mm

Bale Size (L*W*H, H is adjustable)

1100*700*(300~900)mm

1200*800*(400-1000)mm

Bale Weight

60~150kgs

150-350kgs

Power

5.5kw

11kw

Machine Weight

1900kgs

2300kgs

Machine Overall Dimension

1500*1050*1900mm

1650*1200*3300mm
